High-speed barrier gate operators designed for parking lot entrances and traffic control. Features integrated crowd-management logic, emergency egress release, and rapid open/close cycles to keep vehicles moving smoothly.
| Feature | GLWD-S | GLWD-X |
|---|---|---|
| Lift Speed | 1.0–1.2 sec | 0.8–1.0 sec |
| Cycle Capacity | Up to 12,000/day | Up to 12,000/day |
| Ideal For | Parking, toll stations, residential | High-security, industrial, transit |
| Battery Backup | Operates 50–200 cycles | Operates 50–200 cycles |
| Model GLWD- | Max. Arm Length (ft) | Time to Open (sec) | Articulated Arm | Cycles/Day |
|---|---|---|---|---|
| GL | 10 | 1–6 | Available | 5,000 |
| GB | 14 | 1–6 | Available | 8,000 |
| GM | 18 | 1–6 | No | 8,000 |
| GH | 20 | 2.5–8 | No | 5,000 |
| Attribute | Details |
|---|---|
| Mounting Options | Side or shaft mount (left/right configurable) |
| Motor Type | Brushless DC servo with sealed stainless steel bearings |
| Torque Output | 400–600 in-lbs |
| Speed Range | 100–180 RPM (programmable) |
| Boom Support | 10, 12, 14, 16, or 24 ft wood or aluminum |
| Maintenance-Free | No belts, limit switches, hydraulic cylinders, or load springs |
| Brake | Electro-mechanical holding brake with manual disengage |
| Feature | Description |
|---|---|
| Control Tech | Closed-loop motion profiling (AlgorithmDrive™4-quad) |
| Limit Settings | Electronic open/close limits; no mechanical switches |
| Speed Adjustment | Fast open/close speed; on-site adjustment |
| Soft Start/Stop | S-curve profiling reduces mechanical stress |
| Obstruction Sensing | Programmable threshold with smooth reversing |
| Interlock | Security system integration |
| Feature | Description |
|---|---|
| Voltage Range | 115–575 VAC, 1-/3-phase, 50/60Hz (single operator) |
| Battery Backup | 36 VDC optional for brownout or power loss |
| Accessory Power | 24 VAC and 24 VDC for external devices |
| Diagnostics | Intelligent Diagnostic™ clear-text LCD & keypad |
| I/O | 7 programmable inputs; 2 outputs; computer interface |
| Network | Up to 128 units via NetworkPower™ |
| Cycle Counter | Built-in counter for usage tracking |
| Certifications | UL, ULC listed; UL325 compliant (optional) |
| Add-On | Description |
|---|---|
| Gate Arm Options | Articulating or straight arm |
| Cabinet Heater | Thermostat-controlled |
| Opto-Block™ | Photo-eye safety integration |
| Battery Backup Kit | 36 VDC intelligent charging |
| NetworkPower™ | Remote diagnostics & monitoring |
| Application | Description |
|---|---|
| Parking Facilities | Continuous 24/7 high-cycle access |
| Transit & Logistics | Rapid, reliable gates for freight & public |
| Government & Municipal | Secure, compliant access points |
| Commercial Complexes | Gated entry & traffic management |
| Toll Stations | Fast cycle times for continuous traffic flow |
Download the 2-page GLWD Operator spec sheet for engineering and planning.
